Q115 Circuit Breaker, Mini, 15 A, 1 -Pole, 120/240 V, Fixed Trip, Plug Mounting
Sku: 6942957-052303-18
$7.95
80 Available at
SHIP TO STORE
Non-interchangeable trip. 120 VAC, 10,000 AIR. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (Full size only), General Switch, I-TE, Gould, Montgomery Ward and Sears. UL listed, HACR rated. 15 and 20 A UL listed for frequent switching applications, 120 VAC fluorescent lighting. 1 in per pole.
Type
Mini
Voltage Rating
120/240
Current Rating
15
Operating Frequency
50/60
Number of Phases
1
Number of Poles
1
Interrupt Rating
10
Frame Type
QP
Actuator Type
Magnetic, Thermal
Trip Type
Fixed
Wire Size
14 to 8
Terminal Type
Lug
Mounting Type
Plug
Dimensions
3 in L x 1 in W x 3 in H
Operating Temperature
40
